Product Description
CALDRON CS9060 / CS1390 Acrylic/Wood Laser Engraver
The CALDRON CS9060/CS1390 is an acrylic laser cutting machine that keeps cutting 25mm thick acrylic with smooth, sawtooth-free edges, and fast-cuts 2mm small circles without deformation. Suitable for acrylic, LGP, MDF, plywood, advertisement, and decoration materials, it's available in two sizes — CS9060 (900mm x 600mm) and CS1390 (1300mm x 900mm) — to match your workshop space and production needs.
Key Features
✔ Clean 25mm Acrylic Cutting
Smooth, sawtooth-free edges even during long, continuous cutting sessions.
✔ Fast Detail Cutting
Fast-cuts 2mm circles without deformation — ideal for intricate signage detail.
✔ Two Size Options
CS9060 (900x600mm) or CS1390 (1300x900mm) to fit your space and material size.
✔ Flexible Laser Power
CS1390: 135W (100-150W optional). CS9060: 80W (60-150W optional).
Specifications
| Model | CS1390 | CS9060 |
|---|---|---|
| Processing Area | 1300mm x 900mm | 900mm x 600mm |
| Max Cutting Speed | 36 m/min | |
| Max Engraving Speed | 60 m/min | |
| XY Positioning Accuracy | 0.1mm/m (± 0.1mm repeated) | |
| Power Supply | 200V ±10%, 50Hz | |
| Laser Power | 135W (100-150W optional) | 80W (60-150W optional) |
| Machine Gross Power | < 1.5 KVA | |
| Running Temp / Humidity | 0°C - 45°C / 5% - 95% RH | |
| Weight | 300 Kgs | 150 Kgs |
| Machine Dimensions | 1800 x 1400 x 1000mm | 1500 x 1100 x 900mm |
| Suitable Materials | Acrylic, LGP, MDF, Plywood, Advertisement & Decoration Material | |
