Product Description
Ceramic Printer T1320-10 | Digital Ceramic Tile Printing Machine & Wide Format Printer
The Ceramic Printer T1320-10 is a wide-format ceramic printing machine built for tile factories and production studios that regularly print tiles wider than standard 740mm or 1170mm machines can handle. With a 1320mm printing width, 10 ink channels, and SEIKO RC1536 printheads, this ceramic printer covers the popular 1200mm×1200mm and 1200mm×2400mm tile sizes that dominate commercial and residential markets. As a wide format printer and large format printer for ceramic substrates, the T1320-10 fills a specific production gap — wider than mid-format machines, more focused than 28-30 channel industrial glaze lines, and priced for factories that need width more than channel count.
For a small printing business that has outgrown a 740mm ceramic printer and needs to print larger tiles, or a sign shop running flex printing and flex printing machines that is adding ceramic production as a higher-margin service, the T1320-10 delivers the width you need without paying for channels you will not use. It uses the same proven SEIKO RC1536 printheads with recirculation design, adjustable drop size from 14~98pl (up to 13~133pl), 360 DPI native resolution, and 37 kHz firing frequency found across the entire T-series platform. With 10 channels supporting CMYK plus extended colours and special effects, print on demand custom tiles, and continuous factory runs, the T1320-10 is practical digital printing equipment that focuses on what matters for most tile producers — width, speed, and reliability. Available in two widths — T1320-10 (1320mm) and T2150-10 (2150mm) — the series scales from wide-format tile production to extra-wide slab printing.
Key Advantages of Ceramic Printer T1320-10
✔ 1320mm Wide-Format Printing
A 1320mm print width handles the most common large-format tile sizes — 1200×1200mm, 1200×2400mm, and similar — in a single pass. For a ceramic printer serving commercial tile markets, this width covers the majority of real-world demand.
✔ SEIKO RC1536 Recirculation Printheads
SEIKO RC1536 industrial printheads with recirculation keep heavy ceramic pigments from settling during long production runs. This is the proven industry-standard head for ceramic printing — reliable, serviceable, and widely available.
✔ 10-Colour Channel Configuration
10 ink channels support CMYK plus extended colours or special-effect inks. For a ceramic printing machine focused on production throughput rather than maximum colour complexity, 10 channels provide the right balance of capability and simplicity.
✔ Adjustable Drop Size 14~133pl
Drop size from 14~98pl (expandable to 13~133pl) gives operators control over fine detail, smooth gradients on marble and wood effects, and heavy ink coverage for dark tile designs and glaze-effect inks.
✔ 37 kHz Firing & 360 DPI
37 kHz firing frequency with 360 DPI native resolution keeps ceramic printing fast enough for continuous factory lines without sacrificing the image quality that customers expect on decorative tiles.
✔ Print-on-Demand Without Screens
Digital workflow means custom tiles, short sample runs, and print on demand designs without screen-making costs. For a small printing business entering ceramic printing, this removes the traditional barrier to custom tile production.
Ceramic Printer T1320 / T2150 Technical Specifications
| ITEM | T1320 - 10 | T2150 - 10 |
|---|---|---|
| Model | T1320 - 10 | T2150 - 10 |
| Printing Area | 1320mm × 2400mm | 2150mm × Limitless |
| Belt Size | 1340mm | 2200mm |
| Printhead | SEIKO RC1536 | SEIKO RC1536 |
| Drop Size | 14~98pl (Adjustable to 13~133pl) | 14~98pl (Adjustable to 13~133pl) |
| Native Resolution | 360 DPI | 360 DPI |
| Firing Frequency | 37 kHz | 37 kHz |
| Max. Channels | 10 Channels | 10 Channels |
| UPS Requirement | 15 kW – 30 kW | 20 kW – 35 kW |
| Air Requirement | 6 Bar, 500 L/Min Compressed Clean Air (Free of Humidity and Oil) | 6 Bar, 500 L/Min Compressed Clean Air (Free of Humidity and Oil) |
| Power Requirement | 380V (3 Phase + Neutral + Ground) 50–60Hz | 380V (3 Phase + Neutral + Ground) 50–60Hz |
| Technology | Digital Ceramic Inkjet Printing System | |
| Applications | Ceramic Tile Printing, Decorative Ceramic Surfaces, Print on Demand Tiles, Industrial Ceramic Decoration, Wide Format & Large Format Ceramic Production | |
*Printing area, belt size, and UPS requirement vary by model (T1320-10 / T2150-10); all other specifications are shared across both models. Specifications as per product datasheet.
Ceramic Printer T1320-10 Common Applications
| Application | Description |
|---|---|
| 🏠 Decorative Wall & Floor Tiles | High-volume digital decoration for residential and commercial wall and floor tiles up to 1320mm width |
| 🏢 Architectural Ceramic Panels | Large format ceramic panels for building facades, lobbies, and commercial interiors |
| 🎨 Customized Ceramic Designs | Print on demand custom patterns, artwork, and personalised tile designs without screens |
| 🏪 Brand Logos & Promotional Products | Corporate branding on ceramic surfaces for retail spaces, restaurants, and hospitality venues |
| ☕ Ceramic Mugs & Tableware | Custom printing on ceramic drinkware and dining products (with appropriate fixturing) |
| 🖼️ Photo & Artwork Printing | High-resolution reproduction of photographs and fine art on ceramic substrates |
| 🛁 Bathroom & Interior Décor | Custom bathroom tiles, shower surrounds, and interior decorative ceramic surfaces |
| 🏭 Industrial Ceramic Decoration | Continuous single-pass production for large tile manufacturing plants |
| Big Slab & Large Format Tiles | Large format floor slabs, wall slabs, and oversized decorative panels (T2150-10 for widest formats) |
| Digital Print Expansion | For businesses moving from flex printing, flex printing machines, or vinyl print workflows into ceramic production |
Ceramic Printer T1320-10 FAQ
Step 1 — Ink Preparation: Ceramic inks containing glass frits, metal oxides, and mineral pigments are loaded into the ceramic printing machine. These inks are heavier and more abrasive than solvent inks used in flex printing machines, which is why the T1320-10 uses SEIKO RC1536 printheads with recirculation that keeps pigments from settling.
Step 2 — Digital Printing: The tile is placed on the conveyor belt. As it passes under the printheads, the ceramic printer jets the design using variable drop sizes (14~133pl) at 360 DPI and 37 kHz. The T1320-10 uses up to 10 channels for colour and effects.
Step 3 — Drying: The printed tile may pass through a drying section to remove moisture carriers from the ink before firing.
Step 4 — Kiln Firing: This is the step that separates ceramic printing from all other digital printing. The printed tile enters a kiln at 800–1200°C. The glass frits melt and fuse with the tile surface, and the metal oxides develop their final permanent colours. The design becomes part of the tile itself — scratch-resistant, water-resistant, and UV-stable.
Step 5 — Quality Check & Packing: The finished tile is inspected and shipped.
Unlike flex printing where the print is finished off the machine, ceramic printing is only complete after kiln firing. And unlike a ceramic 3D printer that builds shapes from clay, a ceramic printer decorates flat tile surfaces that are already formed.
