Product Description

Glass Printer MGL3760 with 20 SEIKO RC1536 printheads, 2500x4000mm area, zero ink waste, 1440DPI, inline tempering. Best glass printing machine for glass murals, architectural glass panels, glass tiles, backlit glass and large format glass printing.

Glass Printer MGL 3760 | Glass Printing Machine & Large Format Printer

The Glass Printer MGL 3760 is an extra-large Glass Printing Machine and large format printer built for businesses that print on glass panels, glass tiles, and architectural glass at scale. With a maximum printing size of 2500mm × 4000mm and 20 SEIKO RC1536 printheads across 10 channels, this Glass Printer covers the widest glass panels in a single pass — no seaming, no misalignment across 2.5 metres. It achieves up to 1440DPI resolution with variable drop sizes from 14~98pl and intelligent eclosion print technology for sharp detail on everything from 400×400mm samples to full 2.5-metre panels. What truly sets the MGL 3760 apart from other digital printing equipment is its ink efficiency: zero ink waste, lowest ink consumption, and no ink residue on glass — a major advantage when running expensive ceramic inks on large panels where even small waste percentages add up fast. The ceramic ink is directly temped inline after Glass Printing — no separate kiln required, unlike ceramic printing where tiles must go into a kiln after printing. Combined with a synchronous drying system, precisely positioning system for multi-application use, high-speed and stationary printing modes, and a humanized user interface, the MGL 3760 is a large format printer that handles the biggest glass panels a Glass Printing Machine can produce — outdoor murals, building facade wraps, glass tiles, and backlit panels — from one machine, with minimal ink waste and maximum material efficiency.

Key Advantages of Glass Printer MGL 3760

✔ 2500×4000mm Print Area

Handles the largest standard glass panels in a single pass. For a Glass Printer serving commercial glass factories and architectural Glass Printing producers, this large format printer eliminates seaming and alignment issues that come with smaller digital inkjet printer machines.

✔ Zero Ink Waste & No Residue
Cutting-edge ink technology achieves near-zero waste on glass. For a Glass Printing Machine running expensive ceramic inks on 2.5-metre panels, this digital printing equipment feature alone can save significant material cost over time.
✔ 20 SEIKO RC1536 / 10 Channels

20 SEIKO RC1536 printheads across 10 channels deliver the jetting power for consistent Glass Printing on the widest glass panels — more nozzles per pass means faster output with consistent quality on 2.5-metre panels.

✔ Inline Ceramic Ink Tempering
Ceramic ink is applied and cured directly inline — no separate kiln needed. Unlike ceramic printing where tiles go into a kiln after printing, the MGL3760 handles everything in one continuous Glass Printing Machine line.
✔ 1440DPI Variable Drop Size

Variable drop sizes from 14~98pl achieve up to 1440DPI effective resolution. For a large format printer that prints fine-detail architectural glass, the drop size flexibility means sharp details on small 400mm sample panels and smooth gradients on large 2500mm murals from the same Glass Printer.

Glass Printer MGL 3760 Technical Specifications

ITEM SPECIFICATION
Model MGL3760
Max. Printing Size 2500mm × 4000mm
Min. Printing Size 400mm × 400mm
Printhead SEIKO RC1536
No. of Printheads 20 Pcs
Drop Size 14 – 98pl (Adjustable)
Resolution 360 DPI (Up to 1440DPI with Intelligent Eclosion)
Firing Frequency 37 kHz
Max. Thickness 3mm – 25mm
Channels 10 Channels
Air / Power 75kW – 80kW
Printing Mode Stationary / Hi-Speed Mode
User Interface Humanized Interface
Drying System Synchronous Drying System
Positioning System Precisely Positioning System for Multi-Application
Ink Support Ceramic Ink (Directly Temped After Printing), Extensible Ink Channels
Applications Glass Murals, Glass Tiles, Architectural Glass Panels, Backlit Glass, Outdoor Advertising Glass, Vehicle Glass Graphics, Interior Decorative Glass, Commercial Building Wraps, Large Format Glass Printing

*Maximum printing size 2500×4000mm, minimum 400×400mm. Specifications as per product datasheet.

Glass Printer MGL 3760 FAQ

Glass printing uses a specialised Glass Printer — not a standard paper inkjet printer and not a ceramic printer. Machines like the MGL3760 use industrial SEIKO RC1536 printheads with ceramic inks that bond permanently to glass after in-line tempering — no separate kiln required. The Glass Printing Machine jets the design directly onto the glass surface as it passes through, then the ink is cured directly on the machine. This is fundamentally different from tile ceramic printing, where the tile goes into a kiln after printing. A Glass Printer does printing and curing in one continuous line. These machines are used for outdoor glass murals, architectural glass panels, glass tiles, backlit signs, building facade wraps, vehicle glass graphics, and large-format large format printing on glass — work that simply cannot be done on standard digital inkjet printer machines for paper or vinyl. The MGL3760 with its 2500×4000mm area handles the largest glass panels in a single pass, making it a top-tier Glass Printing Machine for commercial glass printing operations.

The cost of a Glass Printing Machine varies widely based on width, printhead count, and whether it is a standalone printer or part of a full production line. Compact glass printers for small studios sit at the lower end. The MGL3760 with 20 SEIKORC1536 printheads and 2500×4000mm print area represents a significant investment due to the large print area and head count. Full production glass lines with pre-treatment stations, UV curing units, and automated glass handling systems are at the highest tier. Beyond the Glass Printer itself, budget for ceramic ink, backing material, glass panels, a cutting table, and proper ventilation are required. However, the MGL3760's zero-waste ink technology helps control ongoing ink costs — a real advantage when running expensive ceramic inks on 2.5-metre glass panels where even small waste percentages add up fast on high-value glass panels. Contact a supplier for specific MGL3760 pricing based on your configuration.

The "best" Glass Printer depends on your panel sizes and production volume. For custom glass studios doing small to medium panels up to 1.8m, a smaller Glass Printing Machine is usually sufficient. For factories printing 2.5-metre wide glass panels, backlit glass, and extra-large architectural glass, the MGL3760 is one of the strongest options. Its 2500×4000mm area prints full-width panels in a single pass with zero-waste ceramic ink technology and a synchronous drying system — no seaming, no misalignment across 2.5 metres. For very high-volume production with pre-treatment and UV curing, a full production line with multiple Glass Printing stations may be better suited. The MGL3760 earns its "best" ranking when you need maximum single-machine width, 20-head printing power, and industrial ink efficiency on the largest glass panels — without the complexity of a multi-station glass line. Note: a ceramic printer prints on tiles, not glass — a Glass Printer prints on glass. They are completely different machines for completely different substrates, even though they may look similar externally.

A Glass Printer like the MGL3760 works through a process that is quite different from both paper printing and ceramic printing:

Step 1 — Glass Preparation: The glass panel is cleaned and pre-treated with a primer to help ceramic ink adhere properly to the surface before it enters the Glass Printing Machine.

Step 2 — Digital Printing: The prepared glass passes under the 20 SEIKO RC1536 printheads. The Glass Printer jets ceramic ink directly onto the glass surface using variable drop sizes and intelligent eclosion print technology for high-resolution output. The MGL3760's precisely positioning system ensures accurate placement on panels up to 2500×4000mm.

Step 3 — Inline Tempering: The printed glass moves through the MGL3760's built-in tempering section. Ceramic ink is heated and cured directly on the glass surface — this is where the ink permanently bonds. No separate kiln needed, which is a major advantage over ceramic printing where tiles must be loaded into a kiln after printing. The MGL3760 handles both printing and curing in one continuous Glass Printing Machine line.

Step 4 — Post-Processing: The printed and tempered glass may receive additional UV curing or lamination depending on the final application — outdoor murals and vehicle wraps, for example, need extra UV protection.

Step 5 — Cutting & Installation: The finished glass panel is cut to size and installed on buildings, vehicles, light boxes, and backlit frames.

Unlike ceramic printing where the ink fires in a kiln after printing, the Glass Printer does it all in one line — print, temper, done. This is why the MGL3760 is a Glass Printing Machine, not just a large format printer adapted for glass — it is purpose-built for the specific chemistry of printing on glass surfaces.
